Titan Wood Install Kit For Structural Post Anchor

From $24.00

Skip to product information
1 of 6
Size
80 in stock

Regular price $24.00
Sale price $24.00 Regular price

β€’Β Elevate appearance and performance
β€’Β Performance matches steel structural posts

The new "Evolution" Structural Wood Post Anchor elevates appearance and performance to new heights. Now you can show off beautiful wood posts and get the performance that matches steel structural posts. It's the smallest, most unassuming yet strongest surface mounted wood post anchor you will find. Stand alone 42" 4x4 posts are rated to a minimum of 500 lbs. on concrete and the 6x6 anchor performs even higher.

Titan Building Products:Β +1 866-577-8868

Installation


Print Installation Instructions

Specifications
Model
VPATSPA-WK35, VPATSPA-WK55
Material Hot Zinc Galvanized Steel
Post Size Nominal 4x4, and 6x6
Recommended Uses & Code Compliance Guard rails on wood. Pergola or pavilion structures. Shade sail surface mounted posts. Light standards. Tested for a minimum of 500# of lateral resistance at top of a stand alone 42" post.
Recommended Wood Species Common construction softwoods such as pine, spruce, cedar, Doug fir, Hem-fir. Not recommended for hardwoods given the difficulty of boring holes into hardwoods such as ipe, cumaru, etc.
